The outlet must be flush with the back wall. IMPORTANT NOTE: The electrical outlet must be placed so the grounding prong is to the right of the thinner blades. A separate circuit, servicing only this appliance is required. Follow the National Electrical Code and local codes and ordinances when installing the receptacle. The electrical supply should be located within the shaded area shown in the illustration below. Masonite, plywood, 1/8" pressed fiberboard, cardboard or other suitable material to protect finished flooring.4' (1.2 m) of 1/4" copper tubing and saddle valve (4200880) for the water line (model UC-24CI).Appliance dolly able to support 130 lbs (59 kg).Allow enough clearance in front of the unit for full door swing.
Use a minimum 3" (76) filler in corner installations to assure a 90° door opening.
IMPORTANT NOTE: To operate properly, the door must open a minimum of 90°. Refer to specifications on the following pages. Undercounter Models OVERALL DIMENSIONS 23 7/8" (606)īefore You Start Make sure the opening dimensions, door clearance, electrical service and plumbing are correct for the model you are about to install. Important product information, including the model and serial number of your unit are listed on the product rating plate, located inside the cabinet, in the upper left area of the unit. You may also check the contact & support section of our website,. Any questions or problems regarding the installation should be directed to your authorized Sub-Zero dealer or Sub-Zero customer service at 80. By reading these instructions carefully, you will make the installation process easier, problem-free and, most importantly, safe. There are key details that you should take special care to observe during the installation. Installation should be done by a qualified installer.īefore you begin the installation process, it is recommended that you read this entire installation guide. Sub-Zero Undercounter Refrigeration IMPORTANT NOTE: The importance of the installation of the Sub-Zero undercounter unit cannot be overemphasized. WARNING states a hazard that may cause serious injury or death if precautions are not followed. CAUTION signals a situation where minor injury or product damage may occur if instructions are not followed. IMPORTANT NOTE highlights information that is especially relevant to a problem-free installation. IMPORTANT NOTE: Throughout this guide, dimensions in parentheses are millimeters unless otherwise specified. Visit /specs for the most up-todate information. 14 Features and specifications are subject to change at any time without notice. To ensure the safe and efficient installation of Sub-Zero equipment, please take note of the following types of highlighted information throughout this guide:
